PS2-100
Self install high efficiency solar pump system
LORENTZ PS2-100 is a high quality, high efficiency, cost effective solar pump system designed for self installation.
PS2-100
Pick it up
a ready to go, system in a box
Plug it in
no wiring to do, just plug in and go
Pump water
from any source: pond, stream, well
PS2-100 is a complete system in a box, ready to take away and carry under your arm. Installation is very easy, just connect the plugs and start pumping water. Even the pipe connection fits standard 1“ hoses, so no special connections to contend with.
The system runs directly from solar, pumping water through the day. The high efficiency means enough water is pumped during the day and can be stored in a tank for night time use if needed.
There are no expensive batteries required.
Being a submersible pump, you are not limited to the water sources that you can pump from. Pumping water from a well, pond, tank or lake can all be done without being concerned about suction head limits as you would be with a surface pump.
The PS2-100 system provides over 20,000 liters of water per day and pumps up to 40 meter heads.
This serves a wide range of opportunities in providing drinking water, water for livestock and for irrigation.
The pump is flexible to serve a wide range of flow and head requirements and designed for the long life needed in productive use cases such as livestock water and for irrigation. It is also suitable for drinking water use for homes.
- There are three different pumps to choose from in the PS2-100 range: HR23, HR14 and HR07.
- The chart shows the daily water that will be pumped at different vertical heads.
- Measure the vertical distance that you need to pump water and look on the bottom axis, read across to the left to see how much water to expect per day.
Data provided is the annual daily average based on using a single 205 Wp PV module at location 15N 0E. There are three pump end variants that cover the range of head and flows, please ask your retailer for advice on choosing the one to meet your needs.
